Vacuum pressure adsorption adsorption oxygen production device, under normal temperature conditions, the use of molecular sieve selective adsorption of nitrogen in the air, reduce the adsorption tower pressure to desorption adsorption of nitrogen in molecular sieve, so as to achieve adsorption - desorption cycle operation, continuous production of purity of 80%~95% or more oxygen.
1. The filtered air is transported by the blower and enters the adsorption tower A or B equipped with molecular sieve and activated alumina. When the air flows through the molecular sieve fixed bed in the tower, nitrogen molecules in the air are diffused into the molecular sieve solid under the adsorption force, and oxygen molecules and argon atoms pass through the bed tothe buffer tank for users to use.
2. After a period of adsorption, the molecular sieve particles are filled with nitrogen molecules, reaching the stage of adsorption saturation. At this time, the air inlet valve is closed, and the oxygen-rich air in the tower is used to wash the other tower just pumped. When the pressure drops to a certain value, the pressure equalizing valve is closed, and the inlet valve of the vacuum pump is opened to vacuum the tower body, and nitrogen is discharged.
3. After a certain degree of vacuum, use the oxygen rich in another tower and the middle part of the buffer tank product gas to wash the molecular sieve, so as to make the adsorbent completely desorption. After the desorption process of adsorbent is completed, the tower is charged with product gas, and the buffer valve is closed when the pressure reaches a certain low vacuum value, and the outlet valve of the blower is opened to charge the adsorption tower, so as to prepare for the next adsorption.
| Main technical parameters of VPSA equipment | ||||
| Model | O2 | Air flowrate | O2 pressure | O2 purity |
| 150 | 150 | 0.9 |
20KPa |
25%-93% |
| 200 | 200 | 21 | ||
| 300 | 300 | 42 | ||
| 500 | 500 | 71 | ||
| 800 | 800 | 133 | ||
| 1000 | 1000 | 142 | ||
| 1500 | 1500 | 212 | ||
| 2000 | 2000 | 283 | ||
| 3000 | 3000 | 425 | ||
| 5000 | 5000 | 708 | ||
| 8000 | 8000 | 1130 | ||
| 10000 | 10000 | 1416 | ||
Reliable and Efficient
Designed for 24/7 continuous operation, ensuring reliable and cost-effective performance.
Intelligent and Convenient
One-touch startup and fully automated operation, providing oxygen supply whenever needed.
Multiple Protections
Long lifespan of molecular sieves up to 100,000 hours, with robust and stable built-in air compressor and air treatment systems.
Robust and Stable
Equipped with quality air compressors and air treatment systems for stable operation.
Adaptability to High Altitudes
Specially designed for high-altitude environments, suitable for altitudes below 5000 meters.
Quiet Operation
Sturdy construction and special noise reduction design of the enclosure, minimizing disturbance from noise.
In addition to VPSA Oxygen Generators, we also produce PSA Oxygen Generators, storage tanks, heat exchangers and other products. If you are interested in VPSA Oxygen Systems or other products, please feel free to send an email to info@gneeheatex.com. We will be very happy to serve you.
Q: What is your main product ?
A: Oxygen gas plant
Q:How to get a prompt quotation?
A:When you send us inquiry, please kindly tell us the below technical information.
1) O2 Production capacity: ____Nm3/h
2) O2 Purity: ____%
3) O2 Discharge pressure: ____Bar
4) Local Voltages and Frequency: _____V/PH/HZ
5) Application or use for which industry:_____(industrial use or medical use,etc)
6) Altitude and atmospheric conditions:_____m
Q:Standard requirements for special equipment execution?
A: GB or ASME /Others
Q: How do you pack the product before delivery?
A: We packed in accordance with the export standards.
Q:What about order process?
A:a. Inquiry---provide us all clear requirements.
b. Quotation---official quotation form with all clear specifications.
c. Contract confirmation---provide correct contract details.
d. Payment terms
e. Production
f. Shipping
g. Installation and commissioning
Q:Terms of payment?
A:We have flexible and active payment terms.
Q: Which payment terms you can accept?
A: We can accept flexible payment include Bank Transfer, LC, DP, West Union, Paypal, or Combination terms as negotiation.
Q: Can you do OEM and ODM?
A: Yes, OEM and ODM are both available for us. With the requirements customization of the material, colors, style, the basic quantities will be advised after we discussed together.
